Appliance on libvirt/KVM

How to deploy and manage the x86 thin appliance (ADR-103) as a libvirt/KVM guest, with a self-renewing TLS certificate and no inbound ports. The worked example is the cube deployment (kg.broccoli.house), but the procedure is generic.

The appliance is thin: container images pull on first boot, secrets are minted per-instance, and the box carries no baked .env. The image is built by appliance/build-appliance.sh; this page covers everything after you have a kg-appliance-*.qcow2.

What you get

A single VM that boots, mints its own secrets, pulls images, and starts the full stack (traefik / web / api / postgres / garage / operator).
Self-renewing TLS via in-container ACME DNS-01 (lego + a DNS provider such as porkbun) — the TLS guide and ADR-105 cover the cert design. DNS-01 is the only ACME challenge that works for a private box (RFC-1918, no inbound :80/:443) that owns a public DNS name.
Management without SSH — the appliance ships no sshd. You drive it through the qemu-guest-agent, the Cockpit host console (:9090), or the tty1 console TUI over VNC.

Pick your path

The worked example below (§1–§2) is the declarative seed path — pinned hostname, self-renewing TLS, zero-touch. Most people don't need that. Three paths, by what you're running and which release artifact fits:

You run…	Use	How
VirtualBox / VMware / Hyper-V	`kg-appliance-<ver>-generic.ova`	the hypervisor's Import Appliance wizard reads the OVF and builds the VM. Use the generic OVA — its console is legible in the VM window; the cloud OVA is 80×25 (see kernel variants).
libvirt / Proxmox / QEMU	`kg-appliance-<ver>.qcow2.xz`	the native path — no OVA. `unxz` and `virt-install --import` (below).
an `.ova` you already have, on libvirt	the `.ova`	libvirt has no OVA importer. Prefer the qcow2; or `tar -xf` the OVA and `qemu-img convert` its `.vmdk` → qcow2. (`virt-v2v` can* import an OVA, but it's a heavyweight guest-conversion tool — overkill for an image that's already KVM-native.)

On libvirt/qemu the OVA buys nothing — the qcow2 is native and the OVA is pure friction. Reach for *.qcow2.xz. The OVA earns its keep only where there's an import wizard.

Quick start — qcow2, zero-config (no seed)

# download + decompress into a libvirt pool (e.g. /srv/storage/libvirt/images)
gh release download v<ver> -p 'kg-appliance-<ver>.qcow2.xz' -D <pool-dir>
unxz <pool-dir>/kg-appliance-<ver>.qcow2.xz

sudo virt-install --name kg-appliance --memory 4096 --vcpus 2 --os-variant debian12 \
  --import --disk path=<pool-dir>/kg-appliance-<ver>.qcow2,bus=virtio \
  --network bridge=br0,model=virtio --graphics vnc,listen=127.0.0.1 \
  --channel unix,target_type=virtio,name=org.qemu.guest_agent.0 --noautoconsole

--import still needs the full VM definition. It only means "boot the disk, no installer" — you must pass --name/--memory/--vcpus/--disk path=…/--network. A bare virt-install --import file.qcow2 fails with "unrecognized arguments". In the GUI, use "Import existing disk image" and pick OS Debian 12.

First boot is zero-config: the box takes a DHCP IP, pulls the GHCR images, mints per-instance secrets, and comes up on http://<ip>:3000 (HTTP, no TLS). The generated admin password is on the console info menu and in /root/kg-credentials.txt; a sudo host login (kgadmin) lands there too. Sign in, set your own admin password, paste a reasoning key — done. Watch it provision on the console (tty1) or journalctl -u kg-firstboot -f.

Thereafter the box stays current via operator.sh upgrade (pulls fresh GHCR images) — the OVA/qcow2 is a one-time bootstrap seed, not re-downloaded per release (ADR-103 / ADR-119). Want TLS + a pinned hostname instead of zero-config? That's the declarative seed — read on.

1. The NoCloud seed — attach it as a VIRTIO disk

Provisioning config (provision.env) reaches the VM through a cloud-init NoCloud seed: a small ISO with the cidata volume label holding user-data + meta-data.

Critical: attach the seed as a virtio disk, not a SATA/IDE cdrom. The Debian cloud kernel has no AHCI/SATA driver, so a sr0/sda seed is invisible → ds-identify finds no datasource → cloud-init is disabled → the box boots with defaults and your provision.env is silently ignored.

Build the seed (run where you can write, then copy into the libvirt pool):

mkdir -p ~/kg-seed && cd ~/kg-seed
cat > meta-data <<EOF
instance-id: kg-appliance-01
local-hostname: kg-appliance
EOF
cat > user-data <<'EOF'
#cloud-config
write_files:
  - path: /etc/kg/provision.env
    permissions: '0600'
    content: |
      KG_EXTERNAL_URL=https://kg.example.com
      KG_TLS_MODE=letsencrypt
      KG_ACME_CHALLENGE=dns-01
      KG_DNS_PROVIDER=porkbun
      KG_LE_EMAIL=you@example.com
      KG_PORKBUN_API_KEY=pk1_...
      KG_PORKBUN_SECRET_API_KEY=sk1_...
EOF
# label MUST be cidata for NoCloud
xorriso -as mkisofs -V cidata -J -r -o kg-seed.iso user-data meta-data
sudo cp kg-seed.iso /srv/storage/libvirt/images/   # xorriso can't write a root-owned pool dir directly

provision.env is the appliance's single declarative control surface; unknown keys are ignored. See appliance/files/provision.env.example.

2. Define the VM

sudo virt-install \
  --name kg-appliance \
  --memory 4096 --vcpus 2 \
  --os-variant debian12 \
  --import \
  --disk path=/srv/storage/libvirt/images/kg-appliance.qcow2,bus=virtio \
  --disk path=/srv/storage/libvirt/images/kg-seed.iso,format=raw,bus=virtio,readonly=on \
  --network bridge=br0,model=virtio,mac=52:54:00:6e:4a:82 \
  --graphics vnc \
  --channel unix,target_type=virtio,name=org.qemu.guest_agent.0 \
  --noautoconsole

Bridge, not NAT — put the VM on a real Linux bridge (br0 ← <nic>) so it gets a routable address and multiple guests can share the NIC.
Pin the MAC to claim a DHCP reservation (and your public DNS A record). Changing the MAC later is safe — the image matches its NIC by name, not MAC (see Troubleshooting). To repoint an existing VM: virsh shutdown kg-appliance && virt-xml kg-appliance --edit --network mac=<reserved> && virsh start kg-appliance.
The org.qemu.guest_agent.0 channel is what lets you manage the box without SSH.

First boot pulls images and provisions — watch with journalctl -u kg-firstboot -f (via the console). The admin password is written to /root/kg-credentials.txt inside the VM. Then sign in to the web UI at the external URL:

Web UI sign-in at the external URL — app admin via OAuth

3. Managing the box without SSH

The appliance has no sshd. Run commands inside the guest through the qemu-guest-agent from the libvirt host. This helper executes a command in the VM and prints its output:

vmx() {  # usage: vmx "shell command" [wait_seconds]
  local pid
  pid=$(sudo virsh qemu-agent-command kg-appliance \
    "{\"execute\":\"guest-exec\",\"arguments\":{\"path\":\"/bin/sh\",\"arg\":[\"-c\",\"$1\"],\"capture-output\":true}}" \
    | grep -oE '"pid":[0-9]+' | cut -d: -f2)
  [ -z "$pid" ] && { echo "(agent busy / not ready)"; return; }
  sleep "${2:-3}"
  sudo virsh qemu-agent-command kg-appliance \
    "{\"execute\":\"guest-exec-status\",\"arguments\":{\"pid\":$pid}}" \
    | python3 -c 'import sys,json,base64
d=json.load(sys.stdin)["return"]
for k in ("out-data","err-data"):
    if d.get(k): sys.stdout.write(base64.b64decode(d[k]).decode("utf-8","replace"))'
}

vmx "docker ps --format '{{.Names}}: {{.Status}}'"
vmx "cd /opt/kg && ./operator.sh status"

For commands with awkward quoting (heredocs, JSON), base64-encode them: vmx "echo <base64> | base64 -d | sh". Decode out-data and err-data separately — they are padded independently, so concatenating before decoding corrupts the base64.

Other management surfaces:

Cockpit — https://<vm-ip>:9090 (host console: services, storage, logs, updates). Cockpit authenticates against OS accounts, not the app's OAuth admin. First boot provisions a sudo-enabled login (kgadmin by default) — set it declaratively with KG_HOST_LOGIN_USER / KG_HOST_LOGIN_PASSWORD in provision.env, or let it mint a random password recorded in /root/kg-credentials.txt. Reset it later with sudo /opt/kg/appliance/files/kg-host-login.sh.
virt-manager — connect to qemu+ssh://<user>@<host>/system for lifecycle + the VNC console. The remote graphical console has three wiring requirements (see below) that each fail with an unhelpful message.
Console TUI — tty1 over VNC offers status / logs / restart / credentials / operator shell. Its "Login shell (host)" option drops to a root shell with no password — that's the intended way to a host shell (the serial/SSH root login stays locked).

Remote graphical console (virt-manager / virt-viewer)

Getting the VNC console to open from another machine needs three things lined up. Each failure mode looks different, so they're easy to chase one at a time:

Key auth the GUI session can use. virt-manager spawns ssh inside your desktop session, which often lacks the SSH_AUTH_SOCK your terminal has — so it can't see your agent and falls back to a password prompt. Pin the key in ~/.ssh/config so no agent is needed (use a passphrase-less key, or ensure the agent is exported to the GUI session):
```
Host <libvirt-host>
    HostName <libvirt-host>
    User <user>
    IdentityFile ~/.ssh/<key>
    IdentitiesOnly yes
```
VNC must listen on 127.0.0.1, not 0.0.0.0. With a routable listen address virt-manager tries a direct connection to host:5900 (usually firewalled → "Viewer was disconnected"). Binding to localhost forces it to tunnel over SSH instead — and closes the passwordless-VNC exposure. Set it (takes effect after a full power-off, not a reboot):
```
virsh shutdown <dom>; virt-xml <dom> --edit --graphics listen=127.0.0.1; virsh start <dom>
```
netcat on the libvirt host. virt-manager's SSH tunnel pipes the VNC socket through nc on the remote host; without it the tunnel dies with "Viewer was disconnected" and sh: line 1: nc: command not found. Install it: pacman -S openbsd-netcat (Arch) / apt install netcat-openbsd (Debian).

Fallback that needs none of virt-manager's auto-tunnel: forward the port yourself and point any VNC viewer at localhost:

ssh -L 5901:localhost:5900 <user>@<libvirt-host>   # keep open
remote-viewer vnc://localhost:5901                  # or gvncviewer localhost:5901

virt-manager graphical console connected to the appliance VM over qemu+ssh

Cockpit behind Traefik (`/cockpit`)

Cockpit's own cert on :9090 is self-signed, and HSTS on the main hostname stops a browser from clicking through it. So the appliance fronts Cockpit through the same Traefik door at https://<host>/cockpit/, sharing the trusted cert. It's on by default (KG_COCKPIT_PROXY, when KG_EXTERNAL_URL + KG_TLS_MODE=letsencrypt are set); =false opts out and leaves Cockpit only on :9090.

How it fits together (Cockpit runs on the host, which Traefik's docker provider can't see directly): - kg-cockpit-proxy.sh writes /etc/cockpit/cockpit.conf (UrlRoot=/cockpit, Origins from KG_EXTERNAL_URL, AllowUnencrypted) so Cockpit serves the sub-path and accepts the proxied origin's login WebSocket. - docker-compose.traefik-cockpit.yml adds a tiny socat sidecar that Traefik routes /cockpit to; it TCP-forwards to the host's :9090 via the Docker host-gateway. A redirectregex middleware 301s the bare /cockpit → /cockpit/ (Cockpit drops the slashless prefix, which would otherwise surface as a 502).

Log in with the OS account (kgadmin by default — see the host-login section above). Reset the Cockpit config later with sudo KG_EXTERNAL_URL=https://<host> /opt/kg/appliance/files/kg-cockpit-proxy.sh.

Gating who can reach it. Cockpit is root-capable, so a source-IP allowlist sits in front of its PAM login (defense in depth). It defaults to open (works as-is); lock it to a LAN/VPN/admin range from the console TUI ("Cockpit /cockpit access control") or:

./operator.sh cockpit-access            # show current
./operator.sh cockpit-access private    # RFC-1918 only (refuses public IPs)
./operator.sh cockpit-access 192.168.1.0/24,100.64.0.0/10   # custom (subnet + VPN)
./operator.sh cockpit-access open       # back to no restriction

Or declaratively at first boot via KG_COCKPIT_ALLOW_CIDRS in provision.env. A future option is mTLS (a client cert) for a cryptographic gate.

Rotate the host login. kgadmin's generated password is stored in cleartext at /root/kg-credentials.txt and now also gates /cockpit. After first login, change it (passwd kgadmin) and shred the file.

Cockpit login at /cockpit — OS account (kgadmin)

Cockpit dashboard — host services, storage, logs, updates

4. The certificate

With KG_TLS_MODE=letsencrypt + KG_ACME_CHALLENGE=dns-01, Traefik obtains and auto-renews a real Let's Encrypt cert; operator.sh recert is a no-op. The cert and ACME account live in a persisted bind-mount (/opt/kg/docker/acme/acme.json) so renewals survive restarts. Verify from the libvirt host:

echo | openssl s_client -connect <vm-ip>:443 -servername kg.example.com 2>/dev/null \
  | openssl x509 -noout -subject -issuer -dates

Worked example: `cube`

Property	Value
Host	`cube` (libvirt `qemu:///system`), bridge `br0 ← enp2s0`
VM	`kg-appliance` — 2 vCPU / 4 GiB, virtio qcow2 + virtio seed
NIC MAC	`52:54:00:6e:4a:82` → DHCP reservation `192.168.1.82`
DNS	`kg.broccoli.house` → `192.168.1.82` (UniFi)
TLS	in-container DNS-01 via porkbun; self-renewing Let's Encrypt cert
Manage	qemu-guest-agent (`vmx`), Cockpit `:9090`, VNC console

Troubleshooting

virt-manager has no "Import OVA" / the OVA won't open — libvirt has no OVA importer (that's a VirtualBox/VMware/Hyper-V feature). Use the *.qcow2.xz artifact instead ("Pick your path"), or unwrap the OVA by hand: tar -xf kg-appliance-*.ova && qemu-img convert -O qcow2 *-disk1.vmdk kg.qcow2, then virt-install --import that qcow2.
virt-install --import file.qcow2 → "unrecognized arguments" — --import skips the installer, not the VM definition; pass --name/--memory/--vcpus/--disk path=…/--network (see the Quick start). The disk must be --disk path=…, not a bare positional argument.
provision.env ignored / box came up with defaults — the seed was almost certainly attached as a SATA cdrom. The cloud kernel can't see it; reattach as a virtio disk (§1). Confirm cloud-init found it: vmx "cloud-init status --long" should name a config-disk datasource.
NIC has no address after a MAC change — only affects images predating the MAC-agnostic networking fix. Current images disable cloud-init's network rendering and ship a DHCP netplan matched by interface name (e*), so MAC changes are safe. If stranded, rewrite /etc/netplan/50-cloud-init.yaml to match by name and netplan apply.
Traefik can't reach Docker (client version 1.24 is too old) — Traefik v3 hard-codes Docker API 1.24 while Engine ≥25 serves a minimum of 1.40. Current images bake DOCKER_MIN_API_VERSION=1.24 as a docker.service drop-in. To fix a running box: write that drop-in and systemctl restart docker.
TLS stuck on the self-signed default / acme.json empty — Traefik only requests a cert for a declared domain; it does not mint on-demand from SNI. Ensure EXTERNAL_URL/TLS_DOMAIN is a public FQDN (not localhost) so the letsencrypt overlay's tls.domains is populated. operator.sh start warns when it isn't.
virt-manager console "Viewer was disconnected" / asks for a password — the remote graphical console needs key auth the GUI session can use, VNC bound to 127.0.0.1, and netcat on the libvirt host. See Remote graphical console.
